| Part Number | MF105-2RS |
| Bearing type | BALL |
| Structure | Single Row |
| Load Direction | Radial |
| Seal type | Rubber seals |
| Bore diameter(d) | 5mm |
| Outer diameter(D) | 10mm |
| Flange OD | 11.2mm |
| Width(B) | 4mm |
| Flange thickness | 0.8mm |
| radius | 0.15mm |
| material | Chrome steel 52100(Gcr15) |
| ring material | Chrome steel 52100(Gcr15) |
| cage material | 300 Series Stainless Steel |
| ball material | Chrome steel 52100(Gcr15) |
| shields material | 300 Series Stainless Steel |
| Grade | ABEC-1(higher grade available) |
| Clearance | C0(other clearance available) |
| BALL SIZE(mm) | 1.588mm |
| BALL QTY | 8 |
| lubrication | grease(oil available) |
| Temperature Range | -30℃~130℃ |
| weight(g) | 0.62 |
| ISO9001:2015 | PASSED |
| REACH | PASSED |
| ROHS | PASSED |
| Dynamic Load Rating (Cr) | 609N |
| Static Load Rating (Cor) | 226 N |
Sealed Flange Bearings is also called sealed flange ball bearings, it is referred flange bearings with rubber seals.Usually there are three types of flange bearings, one is with open type,one is with shields,and one is with rubber seals. Different types with different advantages.Compared with open type and shields types, sealed flange bearings can keep from rust and water.
MF105-2RS is one of pop sealed flange bearings,with a bore diameter 5mm,a outer diameter 10mm and a width 4mm, and it can support the dynamic load rating 431N, it is a very pop sizes in market.
Established in 2007, Zhangzhou Runstar Bearings Manufacturing Co.,Ltd is a professional sealed flange bearings manufacturer for industries in China. Equipped with advanced production line and inspection instruments, Runstar have our own factory of nearly 5000 square meters and we have our own professional R&D teams to supply and solve the solutions for industries.we design and manufacture sealed flange bearings with a grade from ABEC-1 to ABEC-9,the material of flange bearings from Runstar can be chrome steel,stainless steel or hybrid ceramic for choice. All sealed flange bearings from Runstar are strictly controlled under ISO9001:2015,with RoHs and REACH compliance.
BEARING INTERCHANGE
| RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
| MF105-2RS | MF115-2RS |
