| Part Number | MF106 |
| Bearing type | BALL |
| Structure | Single Row |
| Load Direction | Radial |
| Seal type | Open |
| Bore diameter(d) | 6mm |
| Outer diameter(D) | 10mm |
| Flange OD | 11.2mm |
| Width(B) | 2.5mm |
| Flange thickness | 0.6mm |
| radius | 0.1mm |
| material | Chrome steel 52100(Gcr15) |
| ring material | Chrome steel 52100(Gcr15) |
| cage material | 300 Series Stainless Steel |
| ball material | Chrome steel 52100(Gcr15) |
| shields material | 300 Series Stainless Steel |
| Grade | ABEC-1(higher grade available) |
| Clearance | C0(other clearance available) |
| BALL SIZE(mm) | 1.2mm |
| BALL QTY | 10 |
| lubrication | grease(oil available) |
| Temperature Range | -30℃~130℃ |
| weight(g) | 0.55 |
| ISO9001:2015 | PASSED |
| REACH | PASSED |
| ROHS | PASSED |
| Dynamic Load Rating (Cr) | 422N |
| Static Load Rating (Cor) | 174 N |
6mm ball bearings is referred a miniature ball bearings with a bore diameter 6mm.MF 106 is one of 6mm ball bearings in Runstar. It is with a bore diameter 6mm,a outer diameter 10mm, and a width 2.5mm, and it is designed to support the dynamic load rating 496 N.
Established in 2007, Zhangzhou Runstar Bearings Manufacturing Co.,Ltd is a professional 6mm ball bearings manufacturer for industries in China. Equipped with advanced production line and inspection instruments, Runstar have our own factory of nearly 5000 square meters and we have our own professional R&D teams to supply and solve the solutions for industries.we design and manufacture 6mm ball bearings with a grade from ABEC-1 to ABEC-9,the material of 6mm ball bearings from Runstar can be chrome steel,stainless steel or hybrid ceramic for choice. All 6mm ball bearings from Runstar are strictly controlled under ISO9001:2015,with RoHs and REACH compliance. We export 6mm ball bearings wordly,and they are well-known for high precision,high speed,low voice and long life, most of them are widely used in precision instrument,home application,medical device,massage equipment,sports equipment,textile machinery,woodworking machinery,motor,power tool,water pump,air compressor,fishing reel and Yoyo etcs.
BEARING INTERCHANGE
| RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
| MF106 | LF-1060 | MF106 |
